概述：
★該機是穿流連續式干燥設備，用于透氣性較好的片狀，條狀，顆粒狀物
料的干燥，對于脫水蔬菜，中藥飲片等含水量高，而溫度不允許高的物料
尤為合適，該系列干燥機具有干燥速度快，蒸發強度高，產品質量好的優
點。對脫水濾餅狀的膏狀物料，需經造粒或制成棒狀后亦可干燥。
★This machine is a continuous penetrating flow drying equipment
applied .For drying pieces strip and particles state materials with good
ventilation .the machine is suitable for the materials such as
de-watering vegetable, herbal medicine of traditional Chinese medicine
and othersfor which the water contents are high and high drying
temperature is not allowed. The machine owns the advantages, of
fast drying speed, high evaporation capacity and good product quality.
The de-watered filtered cake state paste material should be made into
particles or strips before drying process.
原理：
★物料由加料器均勻地鋪在網帶上，網帶一般采用12-60目不銹鋼絲網，
由傳動裝置拖動在干燥機內移動。干燥機由若干單元組成，每一單元熱風
獨立循環，部分尾氣由專門濕風機排出，廢氣由調節閥控制，熱氣由下往
上或由上往下穿過鋪滿物料的網帶完成熱量與質量傳遞的進程，帶走物料
的水份。網帶緩慢移動，運行速度可根據物料溫度自動調節，干燥后的成
品連續落入收料器中。上下循環單元根據用戶需要可靈活配備，單元數量
亦可根據需要選取
★The materials are uniformly distributed on the mesh-belt by the
material feeder. The mesh-belt Generally adopts 12-60 mesh stainless
steel mesh and it is drawn by a transmission device and move inside
the dryer . the dryer is composed of several sections. For each section
the hot air is circulated separately .part of exhausted gas is exhausted
by a special moisture exhaust blower . the waste gas is controlled by
an adjustment valve. The hot air passes thyough the mesh-belt covered
with bring water material away. The mesh-belt moves slowly, running
speed can be freely adjusted according to the material property. The
final products after the drying process will fall into the material collector
continuously . the top and low circulation units can be freely equipped
according to the user requirements .the number of section might be
selected according to the production demands.
