應用概述 General of applications
★前道工序制好的濕材物料進行擠條─離心拋圓，完成制丸。
★To extrude and spheroidize the fore head process`s wet material on the centrifugal dish and the pellets can be got.
設備特點 Features of equipment
★擠條─拋圓在一臺機器上完成。
★拋丸時，可灑入干粉，不易粘連。
★成丸表面致密，利于包衣。
★成丸粒徑均勻，真球度高。
★Extruding—spheroidizing in one machine.
★No adhesive during spheroidizing as the power is acceded.
★The pellet has compact surface and easy for coating.
★The size distribution of pellet is narrow and high round.
規格 Specification 項目Item | 產量(kg/h) Capacity | 成丸直徑 Dia of pellet | 裝機功率 Power | 外形尺寸 Overall Dimentions |
mini | 1～1.5 | 0.5～3.5 | 4.2 | 650x400x720 |
5 | 3～5 | 0.6～3.5 | 4.2 | 900x680x1100 |
10 | 5～10 | 0.6～3.5 | 8.6 | 1550x950x1350 |
30 | 10～30 | 0.6～3.5 | 17 | 1850x950x1400 |
所有參數僅作參考，視物料情況，本公司擁有變更權利，并不另行通知。
All datas are used for reference only. According to the condition of material, our factory has the right to change but not notice, pardon!
